Type |
35mm focal
plane shutter SLR (Single-Lens Reflex) autofocus / autoexposure
camera with built-in motor drive and retractable flash. |
|
Lens Mount |
Canon EF mount
(electronic signal transfer system). |
|
Usable
Lenses |
Canon EF
lenses. |
|
Viewfinder |
SLR-type,
eye-level roof prism mirror gives 90% vertical and horizontal
coverage of actual picture area and 0.70x magnification with 50mm
lens at infinity. |
|
Mirror |
Quick-return
half mirror. |
|
Standard
Diopter |
Adjusted to -1.
(18.5mm eye relief) |
|
Dioptric
Correction |
-2.5 - +0.5
dpt. |
|
Depth-of-Field Preview |
Enable with
depth-of-field preview button. |
|
Focusing
Screen |
Fixed,
full-surface new laser-matte screen marked with focusing points. |
|
Viewfinder
Information |
Numbers and
symbols displayed by LCD at bottom of viewing area. (Yellow-Green)
1. Shutter speed (If unsuitable blinks at 2 Hz as a warning.)
2. Aperture (If unsuitable blinks at 2 Hz as a warning.)
3. Indicates AE lock or FE lock (Partial metering at center.)
4. Exposure level scale with dot indicators in 1/2-stop
increments. (±2 stops)
5. Lights when flash is ready; blinks at 2 Hz if flash range is
ineffective during FE lock.
6. Lights during high-speed sync. (FP flash)
7. In-focus indicator. (Blinks at 2 Hz if focus cannot be
achieved.) |
|
Shutter |
Vertical-travel, focal plane shutter with all speeds
electronically controlled. Front and rear shutter curtains both
have dedicated electromagnetic release control. (Curtain speed:
6.3ms / 24mm) |
|
Shutter
Speeds |
30 to 1/2000
sec., Bulb; X-sync at 1/90 sec. Can be set in 1/2-stop increments. |
|
AF Control
System |
TTL-SIR
(Secondary Image Registration) CMOS sensor ( ) |
|
Focusing
Point Selection |
The focusing
point can be selected by camera (Automatic) or by user (Manual). |
|
Focus Modes |
1. Autofocus
One of the following two AF modes is set automatically depending
on the picture-taking mode. The shutter does not release until
focus is achieved.
a. One-Shot AF: Autofocus locks when focusing is achieved.
b. Predictive AI Servo AF: Continuously tracks subject movement
and achieves focus before the exposure starts.
c. AI Focus AF for automatic switching between One-Shot AF and
predictive AF for moving subjects.
2. Manual Focus
Setting the lens' focus mode switch to MF enables manual focusing
with the focusing ring. |
|
Focus
Operation |
Autofocus is
activated by pressing the shutter button halfway. |
|
AF Working
Range |
EV1-18 (at
ISO100) |
|
AF-assist
Beam |
Automatically
emitted when necessary and aimed at the area covered by the active
focus point. |
|
Light
Metering |
1. TTL
full-aperture metering using 35-zone SPC (Silicon Photocell).
Three metering patterns available.
a. 35-zone Evaluative Metering.
b. Central partial metering which covers approximately 9.5% of
finder area.
c. Center weighted average metering (Set automatically in M mode.)
2. E-TTL: 7-point, 35-zone pre-flash metering using Speedlite
550EX, 420EX, or 220EX.
3. A-TTL, TTL Flash Metering: off-the-film, 3-zone A-TTL autoflash
linked to focusing points, 3-zone TTL autoflash metering. |
|
Metering
Range |
EV 1-20 (with
50mm f/1.4 lens at ISO 100) |
|
Exposure
Modes |
1. Intelligent
program AE with variable shift.
2. Shutter speed-priority AE
3. Aperture-priority AE
4. Auto DEP
5. Full Auto (Intelligent program AE, unshiftable)
6. Programmed Image Control Modes: Portrait, Landscape, Close-up,
Sports, Night Portrait and Flash Off
7. E-TTL program flash AE
8. A-TTL program flash AE
9. TTL program flash AE
10. Metered Manual |
|
Exposure
Compensation |
1. Auto
Exposure Bracketing (AEB) up to ±2EV in 1/2 steps.
2. Manual exposure compensation up to ±2 EV in 1/2 steps.
3. Unavailable in the Full Auto and Programmed modes. |
|
Multiple
Exposure |
Up to 9
exposures can be preset. Automatically clears upon completion.
Cancelable midway. |
|
Film Speed
Setting |
ISO 25-5000
automatically set in 1/3 step increments according to DX code. Can
also be set manually from ISO 6-6400 in 1/3 step increments. |
|
Film Loading |
Automatic
prewind system. After film positioning and back cover closure, the
film automatically winds to the 1st frame. |
|
Film
Transport |
Single-frame
advance or continuous advance set automatically according to the
picture-taking mode. |
|
Film Wind |
One of two
modes can be set: Single Frame and Continuous. (In Continuous
Mode, with AF locked, approximately 2.5 fps and in AI Servo AF
Mode, approximately 1.3 fps.) |
|
Film Rewind |
Automatically
rewinds at the end of roll. Midroll rewinding possible. |
|
Quiet Film
Transport |
Film winding
sound level: Approximately 60dB |
|
Film
Transport Confirmation |
By up/down
counting of frame counter in LCD panel. |
|
Type |
Built-in,
retractable TTL autoflash head in the pentaprism. Auto pop-up and
serial-controlled. |
|
Guide Number |
39 ft / 12 m
(ISO 100) |
|
Flash
Coverage Angle |
Covers the
angle of view of 28mm lens. |
|
Recycling
Time |
Approximately 2
seconds. The icon lights in viewfinder when ready |
|
Flash
Duration / Color Temperature |
1ms or less /
equivalent to daylight. |
|
Red-Eye
Reduction |
Red-Eye
Reduction lamp lights while the shutter button is pressed halfway
and focusing and metering are achieved. |
|
Battery |
Two CR2 lithium
batteries housed inside the camera grip. |
|
Battery
Check |
Battery level
is displayed by the battery level indicator on the LCD panel.
Battery level is indicated in one of four levels. |
|
Shooting
Modes |
Full Auto,
Portrait, Landscape, Close-up, Sports, Night Scene, Flash Off,
Intelligent Program AE, Shutter Speed-Priority AE,
Aperture-Priority AE, Manual Exposure, Automatic Depth-of-Field AE
|
|
Continuous
Shooting |
Approx. 2.5
images/sec. |
|
Date/Time
Imprint |
(EOS Rebel Ti
Date only) Day/Month/Year, Month/Day/Year,
Year/Month/Date, Date/Hour/Minute |
|
Size |
EOS Rebel Ti /
EOS Rebel Ti Date
5.12 (W) x 3.46 (H) x 2.52 (D) in. / 130 (W) x 88 (H) x 64 (D) mm |
|
Weight |
EOS Rebel Ti:
12.9 oz. / 365 g without batteries |
